Heavy Duty 3 / 5 Twist Gabion Mesh Machine 20-30 Times / Min Speed

Product Categories
HEBEI DIAOZHUO WIRE MESH EQUIPMENT CO.,LTD
Contact Now

Heavy Duty 3 / 5 Twist Gabion Mesh Machine 20-30 Times / Min Speed

  • 1
  • 2
  • 3

Brand Name : DIAOZHUO

Model Number : DZ60X80 DZ80X100 DZ100X120 DZ66X88 DZ64X85

Certification : CE ISO9001

Place of Origin : HEBEI, CHINA

MOQ : 1set

Payment Terms : L/C, D/P, T/T

Supply Ability : 8 sets per month

Delivery Time : 20-30 days

Packaging Details : woodencase and plastic bags

Price : variable

twist : 3 twist and 5 twist

control : fully automatic

speed : 20-30 times/min

engineer : available to service machinery overseas

product name : selvage mesh making machine

wire diameter : max 8mm

Contact Now

Gabion mesh machine line selvage locked machine automatic replace by hand





Gabion mesh machine also called heavy-duty hexagonal wire netting machine .the gabion mesh machine line is including the weaving machine, the cutting machine, the mesh flatten machine , also including the mesh roll compacting machine and packing machine, this is a complete line of gabion mesh machine. this selvge making machine is widly used by our client because it is free the hands of the workers, no need many people to make the gabion box by hand, save a lot of cost for the clients we have exported to many different countries these years.



machine details

1. control system

2. Winding mesh machine.

3, air compressure

4, wire coils

6, wire tensile system included





Mesh Size Max. Width Wire Diameter

Twisted number



 Main Drive Shaft Speed Motor Capacity Theoretical Speed
mm mm mm r/min KW m/h
60×80 2300 1.6-3.0 3

25



11



 165
80×100 1.6-3.0 195
100×120 1.6-3.5 225
120×150 1.6-3.2 20 255
60×80 3300 1.6-2.8 25 15 165
80×100 1.6-3.0 195
100×120 1.6-3.2 225
120×150 1.6-3.5 20 255
60×80 4300 1.6-2.8 25 22 165
80×100 1.6-3.0 195
100×120 1.6-3.0 225
120×150 1.6-3.2 20 255
60×80 4300 1.6-2.8 5 25 22 165
80×100 1.6-3.0 195
100×120 1.6-3.0 225
120×150 1.6-3.2 20 255
